JS-42-072
JS-42-072
Design Notes
- Code – ASME Sec IV HLW
- Design Pressure – 125 psi
- Test Pressure – 125 psi
- Interior – Ultonium Glass Lining
- Exterior – Baked Enamel Steel Jacket
- Insulation – 2″ R 12.5 Open Cell Foam
- Supports – 2” Rails
- Capacity – 385 Gal. / 432 nominal
- Weight – 913 Lbs.
Material Specifications
- Heads – Carbon Steel
- Shell – Carbon Steel
- Couplings – Carbon Steel
- Flanges – N/A
- Pipe – N/A
- Manway – Carbon Steel
- Jacket – 24 Gauge Steel
| Mark | Dimension | Remark |
| A | 80″ | Overall height |
| B | 46″ | Diameter |
| C | 22.5″ | Circulation |
Bare
Jacketed and Insulated
Bare
Jacketed and Insulated
